Attach the slings as follows:
1 Loop the lifting belt around the planetary gear (be aware of center of
gravity!)
2 Hook the lifting belt into the crane hook
3 Carefully lift the load
4 Check horizontal alignment of the load
5 If the load tilts, reposition the lifting belt loop
The slings are in place.
MaintenanceSERVICE MANUAL Güdel planetary gear NR, SR, PR
