mega macs PC
Working with the mega macs PC
Diagnostics
• Basic settings
• Codings
• Test function
Proceed as follows to prepare vehicle diagnostics:
1. Insert the Bluetooth® adapter into the USB port of the PC.
2. Start the mega macs PC software.
3. Perform steps 1 to 11 as described in the section Vehicle selection (Page 55).
CAUTION
Pulling off of the PC VCI when actuating the clutch
Risk of injury or material damage
Proceed as follows before starting:
1. Apply the parking brake.
2. No gear is engaged.
3. Regard the window with infos and instructions.
NOTICE
Short circuit and voltage peaks when connecting the PC VCI
Danger of destruction of automotive electronics
Switch off ignition before connecting the PC VCI to the vehicle.
4. Connect the PC VCI to the vehicle's diagnostic connector.
Both LEDs of the PC VCI flash. The PC VCI is ready for operation.
5. Select >Diagnostics< in the main menu.
Now you can select the type of diagnostics.
61
