GUTMANN mega macs PC - Calling up Technical Data; Wiring Diagrams; Calling up Wiring Diagrams

mega macs PC
Working with the mega macs PC
Vehicle Information
11.6.5.1 Calling Up Technical Data
NOTE
You need an online connection to access the technical data.
NOTE
The selection of the following possibilities depends on the selected manufacturer and vehicle type:
• Functions
• Assemblies
• Systems
• Data
Proceed as follows to retrieve technical data:
1. Select >Vehicle information< in the main menu.
2. Select Technical data with
.
3. Select the requested data record.
The technical data appear.
Additional image or text information is available if a blue
is displayed at the end of the text. Just click to view
this information.
11.6.6 Wiring diagrams
View a vast number of vehicle-specific wiring diagrams here.
11.6.6.1 Calling Up Wiring Diagrams
NOTE
You need an online connection to access the wiring diagrams.
NOTE
The selection of the following possibilities depends on the selected manufacturer and vehicle type:
• Functions
• Assemblies
• Systems
• Data
Proceed as follows to retrieve wiring diagrams:
1. Select >Vehicle information< in the main menu.
2. Select Wiring diagrams with
.
3. Select the requested assembly.
4. Select the requested system.
Several system types can be installed in one vehicle model range. The system type is mostly written on the ECU or
can be determined through parameter readout.
The wiring diagram appears.
83
