H3C S5560S-EI Series User Manual

1-8
Item S5130S-28S-HI S5130S-52S-HI S5130S-28C-HI S5130S-52C-HI
Power supply
slot
2, on the rear panel 2, on the rear panel 2, on the rear panel 2, on the rear panel
Expansion
slot
N/A N/A 1, on the rear panel 1, on the rear panel
Input voltage
PSR75-12A:
• Rated voltage:
 100 VAC to 240 VAC @ 50 or 60 Hz
 240 VDC
• Max voltage:
 90 VAC to 290 VAC @ 47 to 63 Hz
 180 VDC to 320 VDC
PSR150-A1:
• Rated voltage: 100 VAC to 240 VAC @
50 or 60 Hz
• Max voltage: 90 VAC to 264 VAC @ 47
to 63 Hz
PSR150-D1:
• Rated voltage: –48 VDC to –60 VDC
• Max voltage: –36 VDC to –72 VDC
DC power source for the PSR150-D1 power
supply: –48 VDC power source in the
equipment room or an RPS (H3C RPS800-A
or RPS1600-A)
PSR75-12A:
• Rated voltage:
 100 VAC to 240 VAC @ 50 or 60
Hz
 240 VDC
• Max voltage:
 90 VAC to 290 VAC @ 47 to 63 Hz
 180 VDC to 320 VDC
PSR150-D1:
• Rated voltage: –48 VDC to –60 VDC
• Max voltage: –36 VDC to –72 VDC
DC power source for the PSR150-D1
power supply: –48 VDC power source in
the equipment room or an RPS (H3C
RPS800-A or RPS1600-A)
Minimum
power
consumption
• Single
PSR75-12A
input: 15 W
• Single
PSR150-A1
input: 18 W
• Single
PSR150-D1
input: 18 W
• Dual
PSR75-12A
inputs: 17 W
• Dual
PSR150-A1
inputs: 20 W
• Dual
PSR150-D1
inputs: 23 W
• Single
PSR75-12A
input: 24 W
• Single
PSR150-A1
input: 25 W
• Single
PSR150-D1
input: 25 W
• Dual
PSR75-12A
inputs: 27 W
• Dual
PSR150-A1
inputs: 28 W
• Dual
PSR150-D1
inputs: 30 W
• Single
PSR75-12A
input: 12 W
• Single
PSR150-D1
input: 15 W
• Dual
PSR75-12A
inputs: 14 W
• Dual
PSR150-D1
inputs: 21 W
• Single
PSR75-12A
input: 21 W
• Single
PSR150-D1
input: 26 W
• Dual
PSR75-12A
inputs: 23 W
• Dual
PSR150-D1
inputs: 31 W
Maximum
power
consumption
• Single
PSR75-12A
input: 32 W
• Single
PSR150-A1
input: 34 W
• Single
PSR150-D1
input: 36 W
• Dual
PSR75-12A
inputs: 35 W
• Dual
• Single
PSR75-12A
input: 51 W
• Single
PSR150-A1
input: 52 W
• Single
PSR150-D1
input: 53 W
• Dual
PSR75-12A
inputs: 54 W
• Dual
• Single
PSR75-12A
input: 31 W
• Single
PSR150-D1
input: 33 W
• Dual
PSR75-12A
inputs: 33 W
• Dual
PSR150-D1
inputs: 38 W
• Single
PSR75-12A
input: 50 W
• Single
PSR150-D1
input: 53 W
• Dual
PSR75-12A
inputs: 52 W
• Dual
PSR150-D1
inputs: 57 W
