H3C S5560S-EI Series User Manual

1-10
Item
S5130S-28S-
UPWR-HI
S5130S-28S-
PWR-HI
S5130S-52S-P
WR-HI
S5130S-28C-P
WR-HI
S5130S-52C
-PWR-HI
combo
interface.)
combo
interface.)
ASE-T port
form a combo
interface.)
SFP+ port 4 4 4 4 2
Power
supply slot
2, on the rear
panel
2, on the rear
panel
2, on the rear
panel
2, on the rear
panel
2, on the rear
panel
Expansion
slot
N/A N/A N/A
1, on the rear
panel
1, on the rear
panel
Input
voltage
• PSR180-56A (not supported on the S5130S-28S-UPWR-HI switch):
 Rated voltage range: 100 VAC to 240 VAC @ 50 Hz or 60 Hz or 240 VDC
 Max voltage range: 85 VAC to 290 VAC @ 47 Hz to 63 Hz or 180 VDC to 320 VDC
• PSR360-56A/PSR720-56A:
 Rated voltage range: 100 VAC to 240 VAC @ 50 Hz or 60 Hz
 Max voltage range: 90 VAC to 264 VAC @ 47 Hz to 63 Hz
• PSR1110-56A:
 Rated voltage range: 115 VAC to 240 VAC @ 50 Hz or 60 Hz
 Max voltage range: 102.5 VAC to 264 VAC @ 47 Hz to 63 Hz
• PSR560-56D:
 Rated voltage range: –48 VDC to –60 VDC
 Max voltage range: –36 VDC to –72 VDC
• For PSR560-56D DC input, you can use the –48 VDC power source at the installation
site or an H3C RPS1600-A RPS.
PoE power
capacity
Depends on the power supply configurations. For more information, see Table1-8.
Minimum
power
consumptio
n
30 W 27 W 37 W 38 W 47 W
Maximum
power
consumptio
n (including
PoE power
consumptio
n)
2490 W 920 W 1854 W 965 W 1980 W
Chassis
leakage
current
compliance
UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC 60950-1/GB4943.1
Melting
current of
power
supply fuse
• PSR180-56A (not supported on the S5130S-28S-UPWR-HI switch):
 AC: 6.3 A, 500 V
 DC: 6.3 A, 400 V
• PSR360-56A: 6.3 A, 250 V
• PSR560-56D: 30 A, 75 V
• PSR720-56A/PSR1110-56A: 15 A, 250 V
Operating
temperatur
e
–5°C to +45°C (23°F to 113°F)
Relative
humidity
5% to 95%, noncondensing
