43
Appendix B FRUs and compatibility
matrixes
This appendix describes the field replaceable units (FRUs) available for the S5830V2&S5820V2
switches and their compatibility.
All the FRUs in this appendix are hot swappable.
Power modules
Table 6 Power module specifications
Power module Specifications Remark
LSVM1AC300
Rated input voltage:
100 VAC to 240 VAC @ 50 Hz or 60 Hz.
Max input voltage:
90 VAC to 264 VAC @ 47 Hz to 63 Hz.
Max output power:
315 W.
For more information about the
power modules, see H3C
LSVM1AC300 & LSVM1DC300
Power Modules User Manual.
LSVM1DC300
Rated input voltage:
–48 VDC to –60 VDC.
Max input voltage:
–36 VDC to –72 VDC.
Max output power:
315 W.
LSVM1AC650
Rated input voltage:
100 VAC to 240 VAC @ 50 Hz or 60 Hz.
Max input voltage:
90 VAC to 264 VAC @ 47 Hz to 63 Hz.
Max output power:
650 W.
For more information about the
power modules, see H3C
LSVM1AC650 & LSVM1DC650
Power Modules User Manual.
LSVM1DC650
Rated input voltage:
–40 VDC to –60 VDC.
Max input voltage:
–40 VDC to –72 VDC.
Max output power:
650 W.
Table 7 Switch and power module compatibility matrix
Switch model LSVM1AC300 LSVM1DC300 LSVM1AC650 LSVM1DC650
S5830V2-24S No No Yes Yes
S5820V2-48S Yes Yes No No
S5820V2-52QF
(LS-5820V2-52QF-H3)
Yes Yes No No
S5820V2-52QF
(LS-5820V2-52QF-H5)
Yes Yes No No
S5820V2-52QF
(LS-5820V2-52QF)
Yes Yes Yes Yes
