LED status Description
Flashing green The port is sending or receiving data at 40 Gbps.
Steady yellow
A transceiver module or cable has been correctly installed. The port has a link and is
operating at 10 Gbps.
Flashing yellow The port is sending or receiving data at 10 Gbps.
Off No transceiver module or cable has been installed or no link is present on the port.
10/100/1000Base-T autosensing Ethernet port LEDs
Table 24 10/100/1000Base-T autosensing Ethernet port LED description
Status Description
Steady green The port has a link and is operating at 1000 Mbps.
Flashing green The port is sending or receiving data at 1000 Mbps.
Steady yellow The port has a link and is operating at 10/100 Mbps.
Flashing yellow The port is sending or receiving data at 10/100 Mbps.
Off No link is present on the port.
1/10GBase-T autosensing Ethernet port LEDs
Table 25 1/10GBase-T autosensing Ethernet port LED description
Status Description
Steady green The port has a link and is operating at 10 Gbps.
Flashing green The port is sending or receiving data at 10 Gbps.
Steady yellow The port has a link and is operating at 1 Gbps.
Flashing yellow The port is sending or receiving data at 1 Gbps.
Off No link is present on the port.
Management Ethernet port LEDs
A management Ethernet port has one LINK LED and one ACT LED to show its link and data
transmission status.
Table 26 Management Ethernet port LED description
LED mark Status Description
LINK
Off The management Ethernet port is not connected.
Steady green The management Ethernet port is operating at 10/100/1000 Mbps.
ACT
Off The management Ethernet port is not receiving or sending data.
Flashing yellow The management Ethernet port is sending or receiving data.
