H3C S5830V2 Series User Manual

49
NOTE:
• As a best practice, use H3C SFP transceiver modules, SFP+ transceiver modules, or SFP+
cables for the SFP+ ports on the switch. The H3C SFP and SFP+ transceiver modules and
cables are subject to change over time. For the most up-to-date list of SFP transceiver modules
and cables, contact your H3C sales representative or technical support engineer.
• The S5820V2-48S, S5820V2-52QF (LS-S5820V2-52QF-H3), S5820V2-52QF
(LS-S5820V2-52QF-H5), and 5820V2-54QS-GE switches do not support the
SFP-XG-LX220-MM1310 transceiver module.
For more information about specifications for the SFP transceiver modules, SFP+ transceiver
modules, and SFP+ cables, see H3C Transceiver Modules User Guide.
QSFP+ port
The S5820V2-52QF, S5820V2-52QF-U, S5820V2-52Q, and S5820V2-54QS-GE switches provide
QSFP+ ports. You can install QSFP+ transceiver modules in Table 15, QSFP+ DAC cable
s in Table
16, and QSFP+ AOC cables in Table 18 in the QSFP+ port
s as needed.
Table 15 QSFP+ transceiver modules available for the QSFP+ ports
QSFP+
transceiver
module
Central
wavelength
(nm)
Connector
Fiber type
and
diameter
(µm)
Modal
bandwidth
(MHz × km)
Max transmission
distance
QSFP-40G-SR4-
MM850
850 MPO
Multi-mode,
50/125
2000 100 m (328.08 ft)
4700 150 m (492.12 ft)
QSFP-40G-CSR
4-MM850
850 MPO
Multi-mode,
50/125
2000 300 m (984.25 ft)
4700 400 m (1312.33 ft)
QSFP-40G-LR4-
WDM1300
Four lanes:
• 1271.
• 1291.
• 1311.
• 1331.
LC
Single-mode,
9/125
N/A 10 km (6.21 miles)
QSFP-40G-LR4
L-WDM1300
Four lanes:
• 1271.
• 1291.
• 1311.
• 1331.
LC
Single-mode,
9/125
N/A 2 km (1.24 miles)
Table 16 QSFP+ DAC cables available for the QSFP+ ports
QSFP+ DAC cable Description
Max transmission
distance
LSWM1QSTK0 40G QSFP+ QSFP+ 1m Direct Attach Copper Cable 1 m (3.28 ft)
LSWM1QSTK1 40G QSFP+ QSFP+ 3m Direct Attach Copper Cable 3 m (9.84 ft)
LSWM1QSTK2 QSFP+ QSFP+ 5m Direct Attach Copper Cable 5 m (16.40 ft)
