H3C S6850 Series Installation Guide

9
Switch
model
Installation
method
Chassis dimensions
Distance
between the
front and
rear rack
posts
Rack
requirements
S9850-4C
Mounting brackets
at the port side
• Height—88.1 mm (3.47
in)/2 RU
• Width—440 mm (17.32
in)
• Depth—776 mm (33.55
in)
{ 660 mm (25.98 in)
for the chassis
{ 26 mm (1.02 in) for
the power
module/fan tray
handles
{ 90 mm (3.54) for the
mounting brackets
518 to 923
mm (20.39 to
36.34 in)
• A minimum of
1000 mm (39.37
in) in depth
(recommended)
• A minimum of
130 mm (5.12 in)
between the front
rack post and the
front door.
• A minimum of
750 mm (29.53
in) between the
front rack post
and the rear
door.
Mounting brackets
at the power
module side
• Height—88.1 mm (3.47
in)/2 RU
• Width—440 mm (17.32
in)
• Depth—750 mm (29.53
in)
{ 660 mm (25.98 in)
for the chassis
{ 90 mm (3.54) for the
mounting brackets
518 to 858
mm (20.39 to
33.78 in)
S9850-32
H
Mounting brackets
and long slide rails
(provided)
• Height—43.6 mm (1.72
in)/1 RU
• Width—440 mm (17.32
in)
• Depth—486 mm (19.13
in)
{ 460 mm (18.11 in) for
the chassis
{ 26 mm (1.02 in) for
the power
module/fan tray
handles
621 to 853
mm (24.45 to
33.58 in)
• A minimum of
1000 mm (39.37
in) in depth
(recommended)
• A minimum of
130 mm (5.12 in)
between the front
rack post and the
front door.
• A minimum of
550 mm (21.65
in) between the
front rack post
and the rear
door.
Mounting brackets
and short slide rails
(provided)
401 to 633
mm (15.79 to
24.92 in)
