15
Attaching the mounting brackets and chassis rails to the
chassis
1. Place the wide flange of the mounting bracket against the chassis side panel. Align the
mounting bracket installation holes with the appropriate screw holes in the chassis. Use the
provided M4 screws to attach the mounting bracket to the chassis (recommended torque: 12
kgf-cm).
{ To install the mounting brackets at the port-side mounting position, see Figure 22, Figure
23, Figure 24, Figure 28, Figure 30, and Figure 32.
Use four inst
allation holes to secure the mounting brackets to the S6850-56HF, S6850-2C,
and S9850-4C switches. Use three installation holes to secure the mounting brackets to the
S9850-32H switch.
{ To install the mounting brackets at the power module-side mounting position, see Figure
25, Figure 26, Figure 27, Figure 29, Figure 31, and Figure 33.
Use four in
stallation holes to secure the mounting brackets to the switch.
2. Determine the installation position of the chassis rails based on the position of mounting
brackets and the distance between the front and rear rack posts.
Table 5 Chassis rail installation position
Switch model
Mounting bracket
position
Distance between the front
and rear rack posts
Chassis rail
installation
position
S6850-56HF
(long slide rails)
Port-side mounting
position, as shown
in Figure 22
692 to 788 mm (27.24 to 31.02 in) Position a
692 to 853 mm (27.24 to 33.58 in) Position b
Power module-side
mounting position, as
shown in Figure 25
692 to 788 mm (27.24 to 31.02 in) Position c
692 to 853 mm (27.24 to 33.58 in) Position d
S6850-56HF
(super-short
slide rails,
chassis rails not
reaching out of
the chassis)
Port-side mounting
position, as shown
in Figure 23
401 to 5
00 mm (15.79 to 19.69 in) Position a
457 to 565 mm (17.99 to 22.24 in) Position b
Power module-side
mounting position, as
shown in Figure 26
401 to 500 mm (15.79 to 19.69 in) Position c
457 to 565 mm (17.99 to 22.24 in) Position d
S6850-56HF
(super-short
slide rails,
chassis rails
reaching out of
the chassis)
Port-side mounting
position, as shown
in Figure 24
499 to 6
27 mm (19.65 to 24.69 in) Position a
564 to 692 mm (22.20 to 27.24 in) Position b
Power module-side
mounting position, as
shown in Figure 27
499 to 627 mm (19.65 to 24.69 in) Position c
564 to 692 mm (22.20 to 27.24 in) Position d
S6850-2C
Port-side mounting
position, as shown
in Figure 28
519 to 6
38 mm (20.43 to 25.12 in) Position a
524 to 703 mm (20.63 to 27.68 in) Position b
589 to 768 mm (23.19 to 30.24 in) Position c
654 to 833 mm (25.75 to 32.80 in) Position d
Power module-side
mounting position, as
shown in Figure 29
589 to 7
68 mm (23.19 to 30.24 in) Position e
524 to 703 mm (20.63 to 27.68 in) Position f
520 to 638 mm (20.47 to 25.12 in) Position g
