72
QSFP+ port LED
Each QSFP+ port has a status LED to show its operating status and activities.
Table 35 QSFP+ port LED description
LED status Description
Steady green
A transceiver module or cable has been correctly installed. The port has a link
and is operating at 40 Gbps.
Flashing green The port is sending or receiving data at 40 Gbps.
Steady yellow
A transceiver module or cable has been correctly installed. The port has a link
and is operating at 10 Gbps.
Flashing yellow The port is sending or receiving data at 10 Gbps.
Off
No transceiver module or cable has been installed or no link is present on the
port.
SFP28 port LED
Table 36 SFP28 port LED description
LED status Description
Steady green
A transceiver module or cable has been correctly installed. The port has a link and
is operating at 25 Gbps.
Flashing green The port is sending or receiving data at 25 Gbps.
Steady yellow
A transceiver module or cable has been correctly installed. The port has a link and
is operating at 1/10 Gbps.
Flashing yellow (3 Hz) The port is sending or receiving data at 1/10 Gbps.
Off No transceiver module or cable has been installed or no link is present on the port.
SFP+ port LED
Each SFP+ port has a status LED to show port operating status and activities.
Table 37 SFP+ port LED description
LED status Description
Steady green
A transceiver module or cable has been correctly installed. The port has a link and
is operating at 10 Gbps.
Flashing green The port is sending or receiving data at 10 Gbps.
Steady yellow
A transceiver module or cable has been correctly installed. The port has a link and
is operating at 1 Gbps.
Flashing yellow (3 Hz) The port is sending or receiving data at 1 Gbps.
Off No transceiver module or cable has been installed or no link is present on the port.
