H3C S6850 Series Installation Guide

61
Table 11 Power module specifications
Power module model Specifications Remarks
LSVM1AC650
• Rated input voltage: 100 VAC to 240 VAC @ 50
Hz or 60 Hz
• Max input voltage: 90 VAC to 264 VAC @ 47 Hz
to 63 Hz
• Max output power: 650 W
• Melting current of power module fuse: 10 A, 250
V
For more information
about the power
modules, see H3C
LSVM1AC650 &
LSVM1DC650 Power
Modules User Manual.
LSVM1DC650
• Rated input voltage: –48 VDC to –60 VDC
• Max input voltage: –40 VDC to –72 VDC
• Max output power: 650 W
• Melting current of power module fuse: 30 A, 250
V
Fan trays
Table 12 Fan tray specifications
Fan tray model Item Specifications
• LSWM1FANSA
(from the power
module side to the
port side)
• LSWM1FANSAB
(from the port side
to the power
module side)
Dimensions 40.6 × 42.5 × 118.7 mm (1.60 × 1.67 × 4.67 in)
Fan speed 21000 R.P.M
Max airflow 35 CFM
Input voltage 12 V
Maximum power consumption 30 W
Documentation reference
H3C LSWM1FANSA & LSWM1FANSAB Fan
Tray User Guide
• LSWM1BFANSC
(from the power
module side to the
port side)
• LSWM1BFANSCB
(from the port side
to the power
module side)
Dimensions 80 × 80 × 76 mm (3.15 × 3.15 × 2.99 in)
Fan speed 20000 R.P.M
Max airflow 120 CFM
Input voltage 12 V
Maximum power consumption 57 W
Documentation reference
H3C LSWM1BFANSC & LSWM1BFANSCB
Fan trays User Guide
Expansion modules
The S6850-2C switch provides two expansion slots. The S9850-4C switch provides four expansion
slots. Select expansion modules for the switch as required.
