62
CQ configuration example on WX5002
NOTE:
For Ethernet interface configuration prerequisites on WX5002, see Table 10 .
Network requirements
Configure CQ to assign packets from interface GigabitEthernet 1/0/1 to queue 1 and
specify queue 1 to send 2000 bytes during a cycle of round robin queue scheduling.
Configuration procedure
1. Enter system view:
<Sysname> system-view
[Sysname] undo l2fw fast-forwarding
2. Configure CQ list 1 to assign packets from interface GigabitEthernet 1/0/1 to
queue 1:
[Sysname] qos cql 1 inbound-interface GigabitEthernet1/0/1 queue 1
3. Configure queue 1 to send 2000 bytes during a cycle of round robin queue
scheduling in CQ list 1:
[Sysname] qos cql 1 queue 1 serving 2000
4. Apply CQ list 1 to interface GigabitEthernet 1/0/1, and configure interface
GigabitEthernet 1/0/1 to use the 802.1p priority of received packets for priority
mapping:
[Sysname] interface gigabitethernet1/0/1
[Sysname-GigabitEthernet1/0/1] qos cq cql 1
[Sysname-GigabitEthernet1/0/1] qos trust dot1p
CQ configuration example (on any H3C WX access controllers but
WX5002)
NOTE:
For Ethernet interface configuration prerequisites on different H3C WX access controllers, see
Table 10 . This configuration example was created on WX3024.
