34
Displaying and
ma
intaining Qo
S
po
lic
ies
To do…
Use the command…
Remarks
Display user-defi
ned QoS
policy configuration
display qos polic
y
user-defined
[
policy-n
ame
[
classifier
t
cl-name
]
]
Available in a
ny
view
Display QoS policy
configuration on t
he
specified or all i
nterfaces
display qos policy inter
face
[
interface
-type interface-n
umber
]
[
inbound
|
outb
ound
]
Available in a
ny
view
Display traffic
class
configuration
display traffic clas
sifier
user-
defined
[
tcl-n
ame
]
Available in
any
view
Display traffic
behavior
configuration
display traffic beha
vior
user-
defined
[
behavi
or-name
]
Available in a
ny
view
33
35
Table of Contents
Default Chapter
3
Table of Contents
3
1 ACL Configuration
8
ACL Classification
8
ACL Numbering and Naming
8
Match Order
9
ACL Rule Numbering
11
ACL Rule Numbering Step
11
Automatic Rule Numbering and Re-Numbering
11
Implementing Time-Based ACL Rules
11
Ipv4 Fragments Filtering with Acls
12
ACL Configuration Task List
12
Ipv4 ACL Configuration Task List
12
Ipv6 ACL Configuration Task List
12
Configuring an ACL
13
Creating a Time Range
13
Configuring a WLAN ACL
13
Configuring a Basic ACL
14
Configuring an Advanced ACL
16
Configuring an Ethernet Frame Header ACL
18
Copying an ACL
19
Displaying and Maintaining Acls
20
ACL Configuration Examples
21
Ipv4 ACL Configuration Example
21
Ipv6 ACL Configuration Example
22
2 Qos Overview
24
Qos Service Models
24
Best-Effort Service Model
24
Intserv Model
25
Diffserv Model
25
Qos Techniques
25
Applying Qos Techniques in a Network
26
Qos Processing Flow in an AC
27
3 Qos Configuration Approaches
28
Non-Policy Approach
28
Policy Approach
28
Configuring a Qos Policy
28
Defining a Class
29
Defining a Traffic Behavior
30
Defining a Policy
31
Applying the Qos Policy
32
Displaying and Maintaining Qos Policies
34
4 Priority Mapping Configuration
35
Priority Mapping Overview
35
Priority Mapping Tables
35
Priority Mapping Configuration Tasks
37
Configuring Priority Mapping
38
Configuring a Priority Mapping Table
38
Configuring a Port to Trust Packet Priority for Priority Mapping
39
Configuring the Port Priority of a Port
39
Displaying and Maintaining Priority Mapping
40
Priority Mapping Configuration Examples (on WX Series Access Controllers)
41
Trusted Priority Type Configuration Example
42
Port Priority Configuration Example
43
5 Traffic Policing and Line Rate Configuration
45
Traffic Evaluation and Token Bucket
45
Token Bucket Features
45
Evaluating Traffic with the Token Bucket
45
Complicated Evaluation
46
Traffic Policing
46
Line Rate
47
Configuration Task List
48
Configuring Traffic Policing
48
Configuring Traffic Policing in Policy-Based Approach
49
Configuring Traffic Policing in Non Policy-Based Approach
49
Configuring Line Rate
50
Displaying and Maintaining Line Rate
51
6 Congestion Management Configuration
52
Causes, Impacts, and Countermeasures of Congestion
52
Congestion Management Policies
53
Fifo
53
Priority Queuing
54
Custom Queuing
55
Congestion Management Technology Comparison
55
Configuring PQ
56
PQ Configuration Procedure
57
PQ Configuration Example on WX5002
58
PQ Configuration Example (on any H3C WX Access Controllers but WX5002)
60
Configuring CQ
60
Configuration Procedure
61
CQ Configuration Example on WX5002
62
CQ Configuration Example (on any H3C WX Access Controllers but WX5002)
62
7 Support and Other Resources
64
Related Documentation
64
Contact Us
64
Documentation Feedback
64
Technical Support
64
Typographical Conventions and Symbols
65
Symbols
66
Index
67
