Section 3 Installation
Important Note: Approved personnel only must install or commission the equipment.
3.1 Component list
Compare each item in Figure 5 to the items in the shipment. Keep the packaging
materials to use when the counter is sent to the factory for calibration. If an item is
missing or damaged, contact the manufacturer. Refer to Section 8 on page 49.
Figure 5 Instrument components
1
1 Met One 6000 Particle Counter 8 5-pin connector with clam shell (Ethernet and Wireless
units only)
2 Antenna (Wi-Fi unit only) 9 10-pin connector with clam shell (all units except
Ethernet and Wireless)
3 DIN rail mounting kit 10 RH/Temp probe (optional)
4 DIN rail 11 Isokinetic Probe for 0.1 cfm flow option
5 Clip screw (2x) 12 Isokinetic Probe for 1.0 cfm flow option
6 Clip (2x) 13 External LED Indicator (optional)
7 Service port cable (8-pin DIN to 9-pin serial)
1
Not shown: user manual.
