Hach Met One 6000 Series User Manual

68
FXB communication
B.3.1 Data record format examples
Refer to Figure 29 on page 66 and Table 34 on page 67 for element descriptions.
Flow rate
Flow rate value shown in CFM. A value of 000100 equals .100 CFM. A value of 001000
equals 1.000 CFM.
Calibration value
Calibration value of the sensor. A value of 000100 equals a calibration voltage of 1.00 VDC.
Valid ranges are 0.80 to 1.20 VDC. A reported value outside this range will cause a
calibration alarm to be reported in the status byte.
Air temperature
Air temperature reading from the externally attached environmental probe. A value of
000231 equals 23.1°C.
Relative humidity
Relative humidity reading from the externally attached environmental probe. A value of
000561 equals 56.1% RH.
Table 34 Data record element descriptions (continued)
Information Description
2-channel with flow measurement example:
032408 080715 0100 0.5 000278 5.0 000013 CAL 000100 FLO 000100 LOC 000001 C/S 001512
2-channel with no flow measurement example:
032408 080717 0100 0.5 000278 5.0 000013 CAL 000100 LOC 000003 C/S 00155A
2-channel enviro probe and flow measurement example:
032408 080712 0100 0.5 000278 5.0 000013 R/H 000561 TMP 000231 CAL 000100 FLO 000100 LOC 000002 C/S 0016B1
