Hach Met One 6000 Series User Manual

60
Modbus register maps
A.12 Ethernet configuration
Table 28 shows the register blocks for counters that have an Ethernet module. These
settings will take affect when the settings have been saved and when the counter has
been reset (refer to registers 1101 and 1103 in section A.10).
A.13 Wireless configuration
Table 29 shows the register blocks for counters that have a Wireless module. These
settings will take affect when the settings have been saved and when the counter has
been reset (refer to registers 1101 and 1103 in section A.10).
Table 28 Ethernet configuration
Address Register Description Access Size (bytes) Notes
1300 Ethernet MAC address R 6 bytes 00-0E-1C-XX-XX-XX = default
1303 DCHP enabled R/W 2 bytes 0 = disabled, 1 = enabled
1304 IP address R/W 4 bytes 169.254.1.2 = default
1306 Subnet mask R/W 4 bytes 255.255.0.0 (class B)
1308 Gateway R/W 4 bytes 169.254.1.5 = default
1310 Modbus server port R/W 2 bytes 502 = default
1311 Server R/W 2 bytes Not active—server: 1 (default), client: 0
1312 Remote Modbus server port (client port) R/W 2 bytes Not active—reserved for client apps.
1313 Remote Modbus server IP address R/W 4 bytes Not active—reserved for client apps.
1315 Configuration Port R/W 2 bytes 16000 = default
1316–1399 Expansion
Table 29 Wireless configuration
Address Register description Access Size Notes
1400 Security R/W 2 bytes
None, WEP, WPA,
WPA2
1401 Authentication R/W 2 bytes Open, Shared
1402 WEP encryption R/W 2 bytes 64, 128 bit
1403 WPA encryption R/W 2 bytes TKIP, TKIP/WEP
1404 WPA2 encryption R/W 2 bytes
CCMP, CCMP/TKIP,
CCMP/WEP, TKIP,
TKIP/WEP
1405 Key type R/W 2 bytes Hex, Pass phrase
1406 Network type R/W 2 bytes Infrastructure, Ad-Hoc
1407 Reserved R/W 2 bytes
1408 Auto data rate R/W 2 bytes Fixed, Auto
1409 Data rate R/W 2 bytes
1, 2, 5,5, 11, 18, 24, 36,
54
1410 Channel R/W 2 bytes 1-14
1411-1426 Network SSID R/W 32 bytes ASCII string
1427-1458 Key/Pass phrase W 64 bytes ASCII string
1459 Reserved R/W 2 bytes
1460 Country R/W 2 bytes 0-5
1461 Enable R/W 2 bytes Disabled, Enabled
1462 TX key index R/W 2 bytes 0-3
