Haier LT32F6 - Wall Mounting Installation; Attaching to Bracket

p.09
| HD Ready LCD TV | User Manual
Usie two screws to secure the cover back to the bottom of the TV. 2. See g. 4-3.
Screws
g. 4-3
Use 4 Wall Mount Holes 3.
2
and screws (not included) to mount the TV on the
bracket (not included).
See g. 5.
2
g. 5
For the Wall Bracket - Refer to the user instructions supplied with the wall 4.
bracket (not included).
W
H
TV Screen
Size (inches)
VESA-Compatible
Wall bracket
(W x H mm)
Screw Type
32” 200 x 200 mm Metric 6 x 10 mm
37” 200 x 200 mm Metric 6 x 10 mm
42” 400 x 200 mm Metric 6 x 10 mm
WALL MOUNTING
