Hanasis HIT - I;O Pin Assignment

No
Signal Description
1
2
3
4
5
6
7
8
COM Power 5V
CTS
TXD
RXD
RTS
CTS
GND
RTS
■ COM3, COM4 - Serial port (RJ-45)
■ COM1, COM2 - Serial port (DSUB 9 Pin)
51
96
No
Signal Description
1
2
3
4
5
6
7
8
9
DCD
RXD
TXD
DTR
GND
DSR
RTS
CTS
COM Power 5V or 12V
8888
