Hanasis HIT - HDMI Port; MSR Port (RJ-45): COM5, USB7

No
Signal Description
1
2
3
4
5
6
7
8
VUSB 5.0V
USB DM
USB DP
GND
VUSB 5.0V
TXD
RXD
GND
■ MSR port (RJ-45) : COM5, USB7
8888
1
■ HDMI port
No
Signal Description
1
2
3
4
5
6
7
8
9
TMDS Data2+
TMDS Data2 Shield
TMDS Data2-
TMDS Data1+
TMDS Data1 Shield
TMDS Data1-
TMDS Data0+
TMDS Data0 Shield
TMDS Data0-
No
Signal Description
11
12
13
14
15
16
TMDS Clock Shield
TMDS Clock-
CEC
-
DDC clock
DDC data
10
TMDS Clock+
17
18
19
GND
+5V Power
Hot Plug detect
1
19
18 2
3
