Hanasis HIT - LAN Port (RJ-45 with LED); USB 2.0 Port (TYPE-A); USB 3.0 Port (TYPE-A)

No
Signal Description
1
2
3
4
5
6
7
8
MD0 (+)
MD0 (-)
MD1 (+)
MD1 (-)
MD2 (+)
MD2 (-)
MD3 (+)
MD3 (-)
■ LAN port (RJ-45 with LED)
8888
1
■ USB 2.0 port (TYPE-A)
No
Signal Description
1
2
3
4
VUSB (5.0V)
D-
D+
GND
1 4
■ USB 3.0 port (TYPE-A)
No
Signal Description
1
2
3
4
VUSB (5.0V)
D-
D+
GND
No
Signal Description
5
6
7
8
StdA_SSRX-
StdA_SSRX+
GND_DRAIN
Std_SSTX-
9 Std_SSTX+
1 4
