10
SPECIFICATIONS
3.2. PROBE SPECIFICATIONS
Sensor Inputs 3
Sample Environment Fresh, Brackish, Seawater
Protection Rating IP68
Operating Temperature -5 to 50 °C (23.0 to 122.0 °F)
Storage Temperature -20 to 70 °C (-4.0 to 158.0 °F)
Maximum Depth 20 m (66’)
Dimensions (without cable)
Length 342 mm (13.5”)
Diameter 46 mm (1.8”)
Weight (with sensors) 570 g (20.1 oz.)
Cable Specification
Multistrand-multiconductor shielded cable with internal strength
member rated for 68 kg (150 lb) intermittent use
Wetted Materials
Body ABS
Threads Nylon
Shield ABS and 316 Stainless Steel
Temperature probe 316 Stainless Steel
O-rings EPDM
3.3. SENSOR SPECIFICATIONS
HI7698194-0
pH
Measurement Unit pH, mV (pH)
Measure Range
0.00 to 13.00 pH
±600.0 mV (pH)
Color Code Red
Temperature Range -5 to 55 °C (23.0 to 131.0 °F)
Materials
Tip pH glass
Junction Wick
Body PEI
Electrolyte Gel
Maintenance Solution HI70300 Storage solution
Reference Double junction
Immersion Depth 20 m (65’)
Dimensions
Length 118 mm (4.6”)
Diameter 15 mm (0.6”)
