3 - Description
3.3
ATTENTION! The sprayers serial no. are chipped into the frames right side just in front of the wheel (below the
SafeTrack hydraulic cylinder - if found).
CE identification plate fitted on the frame indicates producer name,
model and a serial number for the sprayer.
Frame, boom centre frame and other main steel components have
identification plates indicating type and part number. (not illustra-
ted)
REFERENCE NO: is the main reference number of the complete
machine
Very strong and compact frame which also has a strong chemical and weather resistant electrostatic lacquer coat.
Screws, nuts, etc. have been DELTA-MAGNI treated to be resistant to corrosion.
The main tank made of impact-proof, UV-resistant and chemical resistant polyethylene, has a purposeful design with no
sharp corners for easy cleaning. Nominal contents 3200, 4400 or 6600 l. A large, easy to read tank contents indicator is
placed beside the platforn and is visible from the tractor cabin. The filling hole is placed so it can be accessed from the
platform. This ensures an easy access for the filling of sprays, cleaning of the tank, etc. The sprayer is also equipped with a
rinsing tank, a clean water tank.
An identification plate fitted on the frame indicates producer name
and model. For information about sprayer weight, dimensions and
max pressures etc., please refer to chapter 8.
Tank
Frame
Identification plates
