4.1
DANGER! Be sure to place sprayer at level and firm ground to
avoid sprayer falling down from the jack.
For the unloading of the sprayer, you need a crane. When unloading
with a crane please observe the lifting points as shown on the pictu-
re, and make sure that the straps or belts used for lifting are strong
enough.
For moving the sprayer or loading it to e.g. a truck it can be pulled in
the hooks at the rear-end (A) or a hook can be fastened into the
hole in the front end of the sprayer (B).
When the sprayer needs wheel mounting, wheel changing, brake or
wheel bearing changing etc. then jack up the sprayer under the axle
as shown.
Jack up the sprayer
Pulling the sprayer at the tie down hooks
Unloading the sprayer from the truck
General info
4 - Sprayer setup
