Harris APEX User Manual

APEX™ Exciter Incorporating FLO™ Technology
Specifications Introduction
2604s100.fm
03/08/07 888-2604-001 Page: 1-5
WARNING: Disconnect primary power prior to servicing.
GPS antenna input Antenna connection is an active input with +5V on the center
conductor. Signal frequency is 1575.42 MHz, level can range from
-133 to -115 dBm, input impedance is 50 ohms.
Table 1-2 Harris APEX Exciter Service Conditions Specifications
Specification Explanation
Ambient temperature 0° to 50° celsius (32° to 122° fahrenheit)
Ambient humidity 0 to 90% relative, non-condensing
Altitude Sea level to 10000 feet.
Physical dimensions 19 inches wide, 5.25 inches high, 24 inches deep
Weight 36 pounds
Electrical Requirements Voltage 85-132/170-264VAC
Current 2.4/0.75 AMPS
Power 200 VA
Frequency 47-63HZ
Fuse size T4A/250V
Table 1-1 Harris APEX
Exciter General Specifications
Specification Explanation

Harris APEX Specifications

General

Brand	Harris
Model	APEX
Category	Transmitter
Language	English
