 1×8_ACO: 1 electrical input (In_A) to 6 electrical outputs and 2 optical
outputs with auto changeover
The signal on In_A is distributed to 6 electrical outputs and 2 optical
outputs. If the signal at In_A disappears, the outputs are switched to In_B
(if a signal at In_B is detected).
When the signal reappears on In_A, the outputs are automatically
switched back to In_A from In_B.
 1×8_ In_1: Electrical In_A to 6 electrical outputs and 2 optical outputs
 1×8_ In_2: Electrical In_B to 6 electrical outputs and 2 optical outputs
 2_1×4: 2 independent 1×4
 Electrical In_A to Out_A, 1 optical output and 3 electrical outputs
 Electrical In_B to Out_B, 1 optical output and 3 electrical outputs
 Input signal presence detect and report
 Automatic input cable equalization for electrical input
 Selectable +6 dB gain to use external passive 75 2×1 splitter (via CCS only)
for electrical input
 Selectable input EQ bypass for electrical input
 Reclockable for 270 Mb/s, 1.485 Gb/s, or 2.97 Gb/s SMPTE and DVB-ASI
signals
 Three selectable reclocking modes (automatic, manual, enforce bypass)
 Automatic bypassing reclock stage if not relockable
 Reclock status and data rate report automatic slew rate control for electrical
outputs
 Optical output protection enable
 Optical output loss alarm
 Optical status for optical output (by CCS)
 Automatic power saving if not input signal or no termination on the output
BNC
 Local and remote control
 Module hot swappable
