Operation
When a frame, back modules, and the front module are set up, plug the front
module into the frame; connect the input and output cables to BNCs on back
module and/or LC fiber optional cables to SFPs; and turn on the power supply of
the frame. After approximately three seconds, the distribution amplifier should
operate properly. Usually there is no need for other operational changes.
Without a CCS remote control system, DA-6804+D series distribution amplifiers
are fully functional in FR6802+ frames. With an installed CCS system (including
6800+ETH module in the FR6802+ frame), distribution amplifier operation can be
monitored and configured on the remote computer display. The J3 jumper must be
set to REMOTE (see Table 2-3 on page 23). If the J3 jumper is not set to this
setting, the distribution amplifier can be remotely monitored only, and remote
configuration is not possible.
