Specifications
NOTE: Specifications and designs are subject to change without notice.
Inputs
Table 4-1 Electrical Channel Input Specifications
Item Specification
Number of inputs DA-DHR6804+D: 2
DA-DH6804+D: 2
DA-DSR6804+D: 2
DA-DS6804+D: 2
DA-HRO6804+D: 1
DA-DHROE6804+D: 0
DA-DHREO6804+D: 2
DA-DHROO6804+D: 0
Signal type 3G-SDI, HD-SDI, SD-SDI, ASI
Connector BNC per IEC169-8
Impedance 75
Return loss > 15 dB, 5 MHz to 1.5 GHz
> 10 dB, 1.5 GHz to 3.0 GHz
Maximum signal level 0.88 V
Cable equalization
3.0 Gb/s
*
1.5 Gb/s
*
270 Mb/s
*
Not for DA-DSR6804+D or DA-DS6804+D
0 – 410 ft (0 – 125 m)
0 – 656 ft (0 – 200 m)
0 – 1,312 ft (0 – 400 m)
