Harris DA-DHR6804+D - Page 64

Chapter 4
Specifications
50
Copyright © 2010, Harris Corporation
Table 4-2 Fiber Optical Channel Input Specifications
Item Specification
Number of inputs DA-HRO6804+D: 1
DA-DHROE6804+D: 2
DA-DHROO6804+D: 2
Wavelength 1260 – 1610 nm
Signal type 3G-SDI, HD-SDI, SD-SDI, ASI
Connector LC
Overload input 0 dBm
Sensitivity
3G-SDI
HD-SDI
SD-SDI, ASI
<-17 dBm
<-20 dBm
<-20 dBm
