Harris DA-DHR6804+D - Temperature; Power Consumption; Start-Up Time

and
Chapter 4
Specifications
52
Copyright © 2010, Harris Corporation
Temperature
Power
Consumption
Start-Up Time
Module start-up time is approximately 3 seconds.
Rise and fall time
3G-SDI
HD-SDI
SD-SDI, ASI
<135 ps
<270 ps
<800 ps
Jitter
3G-SDI
HD-SDI, SD-SDI, ASI
<0.3 UI
<0.2 UI
Table 4-4 Fiber Optical Channel Output Specifications (Continued)
Item Specification
Table 4-5 Temperature Specifications
Item Specification
Performance 41° to 104°F (5° to 40°C)
Operating 32° to 122°F (0° to 50°C)
Table 4-6 Power Consumption Specifications
Item Specification
DA-DHR6804+D
DA-DH6804+D
DA-DSR6804+D
DA-DS6804+D
<3.8 W
<1.5 W sleeping
DA-HRO6804+D
DA-DHROE6804+D
DA-DHREO6804+D
<5.0 W
DA-DHROO6804+D <6.0 W
