Setup
Procedures
DA-6804+D series frames, back connectors, and front modules require different
setup procedures before the modules can be installed in the frame.
Setting Up a
Frame
Frame setup consists of installing a frame into its rack, and then connecting to a
power and/or Ethernet source. See the appropriate frame installation and
operation manual for details on installing and operating the frame and its
components.
If the frame does not have CCS control, plug a power cord (A) to the back of the
frame as shown in Figure 2-1. Plug the other end of the power cord into an
electrical outlet.
Figure 2-1 Connection for Non-CCS Control
