Out 1A Cable Fault [RO]
 Yes
 No
Reports loss of signal or termination
fault for the corresponding output
Out 1B Cable Fault [RO]
 Yes
 No
Reports loss of signal or termination
fault for the corresponding output
Out 1C Cable Fault [RO]
 Yes
 No
Reports loss of signal or termination
fault for the corresponding output
Out 1D Cable Fault [RO]
 Yes
 No
Reports loss of signal or termination
fault for the corresponding output
Out 2A Cable Fault [RO]
 Yes
 No
Reports loss of signal or termination
fault for the corresponding output
Out 2B Cable Fault [RO]
 Yes
 No
Reports loss of signal or termination
fault for the corresponding output
Out 2C Cable Fault [RO]
 Yes
 No
Reports loss of signal or termination
fault for the corresponding output
Out 2D Cable Fault [RO]
 Yes
 No
Reports loss of signal or termination
fault for the corresponding output
Ch.1 Data Rate [RO]
 Unknown
 270 Mb/s
 Bypass
 HD
 3G
Displays locked data rate for channel 1
Ch.2 Data Rate [RO]
 Unknown
 270 Mb/s
 Bypass
 HD
 3G
Displays locked data rate for channel 2
Ch. 1 Re-Clocking Mode
 Auto
 270 Mb/s
 Bypass
 HD
 3G
Selects the reclock rate for channel 1
input
Ch. 2 Re-Clocking Mode
 Auto
 270 Mb/s
 Bypass
 HD
 3G
Selects the reclock rate for channel 2
input
Ch1 Loss of Lock Alarm
 Disabled
 Enabled
Enables or disables the Loss of Lock
alarm on channel 1 (the Loss of Lock
alarm indicates the signal is not
locked)
Table 3-7 DA-DHREO6804+ Remotely Controlled Parameters (Continued)
Bold text = Default setting [RO] = Read only/feedback
Path Parameter Range Description
