NUCLEUS Installation and Operation Manual 19
Chapter 2: Operation
Physical Devices Displays a list of devices (stand-alone devices and
virtual devices) that are controlled by the panel. You
can select each stand-alone device or virtual device
from the list to obtain information about the device,
such as the IP address, frame slots number and
operational state. This option is not used for router
system devices.
Version Info Displays the following information: panel name, the
hardware version number, the software version,
memory size, flash memory size, serial number, and a
list of enabled NUCLEUS options for which a software
license key been entered.
License Key Activates NUCLEUS features (see “Activating
NUCLEUS Control Options with a License Key” on
page 20)
File Manager Displays options for copying and deleting NUCLEUS
configurations (see “Transferring Information with the
File Manager”)
Logout Logs the user out of the current configuration.
Copy All Configs
to USB
Copies all configurations from NUCLEUS to the USB
drive. If the Nucleus/panel name structure does not
exist on the USB drive, NUCLEUS creates it when the
files are transferred to the drive.
Table 2-1. Options Menu Items (Continued)
Menu Name Menu Description
