Chapter 3: Specifications
Dimensions
Connections
Table 3-1. NUCLEUS Dimension Specifications
Item Dimension
Height 3.47 in. (8.8 cm)
Mounting width 17.5 in. (44.4 cm)
Width (including front panel) 19 in. (48.3 cm)
Mounting depth (including
connectors)
Approximately 3.56 in. (9.0 cm)
Depth (front-to-back, including
front panel and back
connections)
Approximately 3.63 in. (9.2 cm)
Table 3-2. NUCLEUS-DM Dimension Specifications
Item Dimension
Height 5.87 in. (14.9 cm)
Width 9.84 in. (25.0 cm)
Mounting depth (including
connectors)
Approximately 9.37 in. (23.8 cm)
Depth (front-to-back, including
front panel and back
connections)
Approximately 9.45 in. (24.0 cm)
Table 3-3. Connection Specifications
Item Specification
Ethernet RJ-45

Harris NUCLEUS Specifications

General

Brand	Harris
Model	NUCLEUS
Category	Control Panel
Language	English
