CONTENTS
CFV 100C
User Manual
6. Circle Button
The button has multiple functions that vary in different scenarios. In Live View or Browse
Mode, press to show or hide parameter information.
7. Browse Button
8. ON/OFF Button
Press and hold for 1 second to power on the camera and the “H” logo will appear on the
touch display.
After a few seconds (customisable) of inactivity, the camera will enter Standby Mode.
Press the button once to enter or exit Standby Mode.
Press and hold the button to power off the camera completely when it is powered on
(not in Standby Mode).
9. Status LED
Indicates the camera status after being powered on. Refer to the table below.
—
Solid green The camera is ready to make a capture.
Blinks green The image is written to the memory card or built-in storage.
—
Solid yellow The camera is busy or not ready to make a capture, such as
when the camera is connecting to a computer as mass storage,
when the lens is not mounted, or when the storage is full.
—
Solid red Error state. Contact the Hasselblad authorised service centre.
10. CFexpress Card Slot
Insert a CFexpress Type B memory card to expand storage.
11. Battery Release Lever
Push the lever to release the battery and then remove the battery.
12. Battery
13. Focal Plane Mark
14. USB-C Port
For charging the battery and image transmission. USB 3.1 is supported. Connect the
port to the provided charger using the USB-C to USB-C cable to charge the battery.
Connect the port to a computer using a USB-C cable of USB 2.0 or above to read
images stored in the camera or for Phocus.
15. Shutter Control Port
Connect the shutter control cable to the port to control the shutter for capture using
external shutter control.

Hasselblad CFV 100C Specifications

General

Sensor Type	CMOS
Sensor Size	43.8 x 32.9 mm
Resolution	100MP
Image Stabilization	No
Video Recording	No
Storage Media	CFexpress Type B
Viewfinder	Optional (via accessory)
Connectivity	USB-C, Wi-Fi
Battery	Rechargeable Lithium-Ion Battery
