135
Chapter XII. Engine management system
(b) Fuel pressure sensor
6. Winding resistance: 1.06ÿ
7. Operating voltage: 65V 8. Peak/
protective current: 10-18A /
2-3A
1. Operating temperature range: -30 to
125
°C 2. Maximum continuous working
pressure: 15 MPa
1. Working pressure range: 0-25MPa 2.
Working temperature range: -40-140°C
3.
Input voltage: 5.0±0.25V 4. Output
voltage range: 0.5-4.5V
3. Maximum opening pressure (short
exposure): 20MPa 4. Maximum fuel leakage
volume: 2.5mm3 /min 5. Maximum idle
time is 30s
at 3000rpm. Provides maximum
(c) Fuel injector specifications:
