Chapter V. Turbocharging System
(a) Install the turbocharger bracket adapter to the cylinder block and secure
with 2 bolts (A).
15. Installation of the exhaust manifold and turbocharger
(b) Attach the bracket to the turbocharger boss with the bolt (C)
ÿ Tightening torque: 22±2 Nm.
ÿ Tightening torque: 55±3 Nm.
(a) Install the connecting stud to the turbocharger.
ÿ Tightening torque: 35±2 Nm.
18. Installation of the supply pipe of the cooling system
(c) Connect the turbocharger bracket to the adapter and
ÿ Tightening torque: 30±2 Nm.
turbocharger
(a) Install the turbocharger cooling system inlet pipe and secure with the
nipple bolt and gasket.
ÿ Tightening torque: 35±2 Nm.
(b) Install the turbocharger inlet gasket and turbocharger to the exhaust
manifold and secure with nuts.
secure with bolt (B).
ÿ Tightening torque: 22±2 Nm.
ÿ Tightening torque: 62±2 Nm.
(c) Install the turbocharger and exhaust manifold to the cylinder block.
17. Installing the turbocharger oil supply pipe
16. Installing the turbocharger mounting bracket
tatelya
(a) Install the turbocharger oil inlet pipe and secure with the socket bolt with
gasket.
21
