4C20 Gasoline Engine Repair Manual
B
A
22
(e) Install the turbocharger oil outlet pipe gasket with the embossed side
towards the pipe.
(b) Install the turbocharger oil outlet pipe with gasket and secure with bolts
(shown by arrows).
(a) Install section II of the turbocharger cooling system outlet pipe to the
engine front cover
19. Installation of section II of the discharge pipeline of the turbocharger
cooling system
body.
ÿ Tightening torque: 10±1 Nm.
(a) Install the turbocharger cooling system outlet pipe section II to the intake
manifold and secure with the bolt (A).
ÿ Tightening torque: 22±2 Nm.
ÿ Bolt A. Tightening torque: 10±1 Nm.
Note:
(b) Fix the corresponding piping with ho
mute.
(c) Install vacuum hose I and outlet hose I of the turbocharger cooling system.
(c) After removing the oil outlet pipe gasket, tour
ÿ Bolt B. Tightening torque: 22±2 Nm.
ÿ Tightening torque: 10±1 Nm.
Torah
(d) Secure the hoses with 4 clamps.
blower needs to be replaced.
21. Installing the exhaust manifold heat shield
(d) Do not install the oil outlet pipe
supercharger without gasket.
20. Installation of the outlet pipe of the cooling system
(a) Install the heat shield to the exhaust manifold mounting lug and secure
with 3 bolts.
turbocharger
