(a) Remove the 4 bolts and remove the throttle body.
ÿ Be careful not to shake
Clue:
throttle block.
1. Turn out a bolt (it is shown by an arrow)
ÿ Disassembly of the throttle body is prohibited!
2. Removing the forced ventilation hose
crankcase
(b) Remove the throttle body gasket.
4. Removing the intake manifold bracket
(a) Loosen the clamp and remove the hose of the forced
(a) Remove the bolt and nut and remove the intake manifold
bracket.
crankcase ventilation.
3. Removing the throttle body with gasket
(b) Remove the intake manifold support.
4C20 Gasoline Engine Repair Manual
24
Disassembly
