novki.
ÿ Tightening torque: 22±2 Nm.
novki.
(c) Install 2 threaded studs (shown by arrows) on the cylinder head.
(d) Install the intake manifold to the cylinder head and secure with 5 screws with
washers and 2 nuts.
9. Assembly of the intake manifold
(a) Check the condition of the throttle body gasket
ki.
ÿ Tightening torque: 22±2 Nm.
(a) Check the condition of the intake manifold gasket.
(b) Do not install the throttle body without
gaskets.
Clue:
(b) Do not install the intake manifold without
(e) Install the bracket support to the intake manifold and secure with the nut.
11. Assembly in the reverse order of removal.
ÿ Tightening torque: 10±1 Nm.
masonry.
ÿ The illustration shows the protection against misalignment.
(c) Install the throttle body to the intake manifold and secure with 4 bolts.
(e) Install the intake manifold bracket and secure with the bolt and nut.
Clue:
ÿ The illustration shows the protection against misalignment.
ÿ Tightening torque: 22±2 Nm.
ÿ Tightening torque: 10±1 Nm.
10. Throttle body installation
4C20 Gasoline Engine Repair Manual
26
Assembly
