Chapter VII. Supply system
7. Removing the high pressure fuel pump support
5. Removing the high pressure fuel pump.
high pressure.
(a) Remove the 5 bolts and remove the fuel pump support
(a) Remove the soundproof cover of the fuel pump
(b) Remove the high pressure fuel pump support gasket.
pressure.
juice pressure.
(b) Remove the 2 bolts and remove the high pressure fuel pump
8. Removing the fuel pump drive cam
(a) Remove the fuel pump drive cam from the support then
pressure.
6. Removing the vacuum pump
high pressure injection pump.
(a) Remove the 2 bolts and remove the vacuum pump.
