4C20 Gasoline Engine Repair Manual
9. Checking the vacuum pump
the cam needs to be replaced.
(a) Check the vacuum pump O-ring for signs of rubber aging, deformation and
damage, and replace if necessary.
nia
(b) Apply sealant at the junction of the camshaft bearing cap and cylinder head
(2.5-3mm).
ÿ Tightening torque: 22±2 Nm.
(b) Make sure the O-ring of the vacuum
ÿ Use 5188 Loctite
10. Installing the high pressure fuel pump support
pump is installed correctly.
(c) Install the fuel pump support gasket high
(a) Do not install the high pressure fuel pump support without the guide pin.
(c) Check the vacuum pump cam for wear. Worn out
pressure, high pressure fuel pump support, and secure with 5 bolts.
Examination
Installation
