Max levelMinimum level
4C20 Gasoline Engine Repair Manual
engine specs”.
8. Preparation for filling with new engine oil
Parameter
(b) Engine oil charge
Refueling volume
(a) Clean the drain plug, install a new gasket, and screw the plug into the oil
pan.
without O-ring.
11. Checking the engine oil level
Including oil filter
volume Without oil
filter volume 10.
Installing and tightening
the oil filler cap
ÿ Tightening torque: 25±2 Nm.
(a) The engine oil level must be between the maximum and minimum marks
on the dipstick.
12. Check engine oil leakage
(a) Start the engine and check for engine oil leakage. If a leak is found,
eliminate its cause.
Note:
Engine oil filling
volume (l)
Studs in the engine during repair may indicate damage to the crankshaft
and main bearing shells. In this case, the following repair is required:
(a) Thoroughly clean the oil passage, replace the piston cooling nozzle, oil
filter and oil
5.0±0.1
ÿ Protective clothing and gloves must be worn when changing engine oil.
Avoid direct contact of the oil with the skin. This can cause dry skin,
irritation and, as a result, dermatitis.
locooler.
9. Filling in new engine oil through the oil filler neck
4.6±0.1
(a) Engine oil grade: see “Chapter II Specifications
neck
13. Identification of a large number of metal teas
(a) Do not install the oil filler cap
50
