engine parts and remove it.
If the gasket is damaged, it must be replaced.
3. Removing the oil cooler. (a)
Remove 4 bolts and remove oil cooler (C). (b) Remove
the oil cooler gasket (B). (c) Inspect the gasket.
If there is a deformity or
2. Removing the oil filter.
1. Removing the oil cooler bracket (a) Remove
the bolts in the reverse order to that shown in the figure. (b) Move
the oil cooler
bracket towards the front
4. Removing the oil cooler connecting tube (a) Remove the
connecting tube (A) from the oil cooler. (b) Check the condition
of the gasket (B).
Chapter IX. Lubrication system
Disassembly
Tip: ÿ Depressurize the fuel lines before removing
the oil cooler.
57
