(b) Install the oil cooler (C) on the oil pump and
ÿ Tightening torque: 22±2 Nm.
fasten with 4 bolts (A).
5. Gasket check.
7. Installing the oil cooler bracket
(3) Insert the connecting pipe into the hole of the oil cooler bracket.
Note:
(a) Install a new oil cooler bracket gasket into the groove.
(a) Check the condition of the oil cooler gaskets and the oil cooler bracket.
If there is damage or deformation, the gasket must be replaced.
ÿ Do not install the connecting pipe (B) without O-rings (A).
(b) Install the oil cooler bracket
(1) Apply a small amount of glycerin to the O-rings (A) for lubrication.
6. Oil cooler installation
(a) Install a new gasket (B) of the oil cooler bracket
(2) Insert the connecting pipe (B) into the oil
body.
locooler.
4C20 Gasoline Engine Repair Manual
Examination
Assembly
ABA
58
