8. Oil filter installation
(c) Fix the oil cooler bracket
body and tighten to the prescribed torque.
(a) Install the oil filter on the oil cooler bracket
(1) Connect the oil cooler bracket to the housing on
ÿ Tightening torque: 20±2 Nm.
9. Installing the drain plug with gasket
cooling system pump.
(2) Install the screw (4).
(a) Apply a small amount of engine oil to both sides of the new gasket.
(b) Install the gasket into the guide groove of the drain plug (the gasket must
not protrude or warp after tightening), and screw the plug by hand.
(3) Install the remaining bolts in 2 stages in the sequence shown in the
figure.
• Tighten the bolt by hand.
(c) Tighten the drain plug to the prescribed torque using a torque wrench.
• Tighten the bolt to 22±2 Nm.
ÿ Tightening torque: 25±2 Nm.
59
Chapter IX. Lubrication system
