Hawk ORCA - Profibus DP

Probus DP
ORCA Sonar System
17
Probus DP
Set the Profibus Address in Sultan
Factory defaults of FBusAdds is 126 in a Sultan unit
with Profibus CommType. To modify this value follow
the instruction below:
1. Go to the Output Adj menu
2. Use the Up and Down push buttons to reach the
CommType parameter
3. Make sure that the CommType is set to
Profibus DP
Failed ~~~~~~ Search 0 Echo Cfm : 1 =
True, 0 = False
Echo R : 1 =
True, 0 = False
4. Press the CAL button twice - If you see DeviceID
do not modify this parameter
6. Use the Down push button to reach the BaudRate
parameter. Note this cannot be modified
8. Use the Down push button to reach the FBusAdds.
The default value of the Fieldbus Address is 126.
Press CAL button and use the Up and Down push
buttons to modify this value
9. Press CAL button again when finish.
Output Data
Profibus/DeviceNet now transmit 18 bytes/9 words, description of the words is as follows (For firmware
version 5.54 and above).
1. Displayed Distance
(Space Distance is the Primary Variable)
2. Percentage (Percent of Range)
3. Hi Level (Upper Range)
4. Low Level (Lower Range)
5. Status Flags
6. Displayed Distance2 (Second Variable)
7. Percentage2 (Second Percent of Range)
8. Displayed Distance3 (Third Variable)+
9. Percentage3 (Third Percent of Range)+
Bit F Bit E Bit 3 Bit 1 Bit 0
Bit0 = Echo was received inside the span.
Bit1 = Echo is Confirmed.
Bit3 = Searching is searching for an Echo.
BitF = Unit has Failed to detect an Echo.
+Only used for ORCA Sonar Clarity output.
