Part Numbering
ORCA Sonar System
36
OSIRT ORCA Sonar Transducer
Transducer Strength
3 Industrial / Mining
Transducer
02 (150kHz)
Facing & Housing material*
S4 Fiberglass face with Polypropylene housing (max 50°C 122°F)
SH Full fiberglass high temperature version (max 80°C 180°F)
Approval Standard
(consult safety instructions for potential IS barrier req)
X Not Required
i0 IECEx Zone 0 (Ex ia IIA T4 IP68 Tamb -20°C to 70°C)
A0 ATEX Grp II Cat 1 GD EEx ia IIA T4 IP68 (Tamb -20°C to 65°C)
A1 ATEX Grp II Cat 2 GD EEx m II IP68 T5 (Tamb -20°C to 65°C)
T6 (Tamb -20°C to 50°C)
i1 IECEx Zone 1 (Ex mb II IP68 T5(Tamb -20°C to 65°C)
T6 (Tamb -20°C to 50°C))
Connection
C IP68 Sealed with 6 metre cable
6 6m cable
15 15m cable
30 30m cable
50 50m cable
FRP Full transducer / pole FRP fibreglass encapsulation
(requires OSIRMELxH) consult factory
OSIRT 3 02 SH X C 6
Remote Sonar Transducer
*Other facing & housing materials including GH and HH are now same specification as SH option.
