Operating Diagnostics
ORCA Sonar System
27
Operating State
In this operational state you can use the
buttons to navigate through and view unit diagnostics and other
measurements.
Diagnostic
Typical Reading
Description
Bed
Distance
Bed indicates Bed height measured from Low Level
Level
Depth indicates depth of measured Density measured from the
transducer face
Bed% % Height of bed level proportionally based on High & Low level
Tx 1 Address of Transducer (default 1)
Normal
Distance
Unit is operating normally
Recover Unit is searching for new signal
Failed Unit is in failsafe mode
W (down) Distance Tracking Window end point (measured from sensor face)
W (up) Distance Tracking Window start point (measured from sensor face)
T: 23.8 Measured Temperature
N: 0.00% Noise (electrical and frequency interference)
R: 0.00% Current Recover Gain added
G: 24.6% Total amount of Gain applied to track current echo
S: 1.60V Signal size in Volts
E: Distance Non-damped measured distance measured from sensor face down
