Hawk ORCA - Specifications

Specications
ORCA Sonar System
38
Sonar Frequency Selection
• 150kHz
Operating Voltage
• 90 - 260Vac 50 / 60Hz
• 24Vdc (min 5A supply)
• Residual ripple no greater than 100mV.
Power Consumption
• <10VA @ 240Vac
• <10W @ 24Vdc.
Analogue Output
• Either single or dual analogue
1 x 4-20mA (isolated) 600 ohms max
1 x 4-20mA (non isolated) 600 ohms max.
Communications
• GosHawk, HART, Modbus, Profibus DP,
DeviceNet, Foundation Fieldbus, Profibus PA.
Relay Output
• 3 x s.p.d.t. 0.5amp / 240vac
• Form c. type non-inductive load
• Fully programmable.
Maximum Range
• 65 meters.
Blanking Distance
• 450mm: 150kHz.
Resolution
• 1mm.
Accuracy
• +/- 0.25%
Operating Temperature
• Remote Electronics: -40°C to 70°C
• Sonar Transducer Polypropylene: -40°C to 50°C
• Sonar Transducer FRP Fibreglass:
-40°C to 80°C.
Transducer / Transmitter Separation
• >500m
Note: Must be BELDEN 3084A
Cable (Sonar Transducer)
• BELDEN 3084A.
Sealing
• Remote Electronics IP67
• Remote Transducer IP68.
Cable Entries
• Remote Electronics: 3 x 20mm 1 x 16mm.
Typical Weight
• Remote Electronics 1kg
• Remote Transducer 1kg
• Cleaning Mechanism 5kg.
IMPORTANT
“USE SPECIFIED CABLE ONLY”
